SSAF VS61 SR
*For vertical glass, 7 year warranty for sloping glass. Warranty is only valid if installed by trained and qualified personnel.
10
Year
Warranty*
Performance Data
Technical data |
4mm single |
4/16/4mm double |
|---|---|---|
| Solar Energy Transmission, Te | 46% | 41% |
| Solar Energy Reflection, Pe | 28% | 29% |
| Solar Energy Absorption, ae | 26% | 30% |
| Visible Light Transmission, Tv | 61% | 56% |
| Visible Light Reflection (External),Pve | 22% | 26% |
| Visible Light Reflection (Internal),Pvi | 21% | 24% |
| Ultraviolet Transmission, Tuv | <1% | |
| g value | 0.51 | 0.56 |
| Shading Coefficient | 0.59 | 0.64 |
| Total Solar Energy Rejected | 49% | 44% |
| Glare Reduction | 32% | |
| U value, single glazing (W/m².K) | 5.39 | |
| U value, double glazing, Air filled (W/m².K) | 2.62 | |
| Emissivity, εn | 0.71 | |
| Film Colour / Appearance | Neutral Bronze | |
| Installation Position | Internal | |
Features and Benefits
- Great visible light transmission and good solar energy rejection.
- Recommended for shop front windows, musemums and historic buildings and other applications where high visible light transmission is desired.
- Rejects up to 49% of total solar energy, reducing heat and energy costs, increasing comfort.
- Optically-clear with advanced infrared rejecting technology.
- Blocks out over 99% of UV radiation, a major cause of fading of valuables, fabrics and furnishing.
- Used where a combination of high light transmission and substantial reduction in solar infrared transmission are needed.
- Protected by a patented scratch-resistant coating, resulting in durable and easy to clean product.
- I.R. 780nm to 2500nm.
