SSAF V14 EX SR
*For vertical glass, 5 year warranty for sloping glass. Warranty is only valid if installed by trained and qualified personnel.
7
Year
Warranty*
Performance Data
Technical data |
4mm single |
4/16/4mm double |
|---|---|---|
| Solar Energy Transmission, Te | 7% | 6% |
| Solar Energy Reflection, Pe | 56% | 57% |
| Solar Energy Absorption, ae | 37% | |
| Visible Light Transmission, Tv | 9% | |
| Visible Light Reflection (External),Pve | 58% | |
| Visible Light Reflection (Internal),Pvi | 24% | 28% |
| Ultraviolet Transmission, Tuv | <1% | |
| g value | 0.16 | 0.11 |
| Shading Coefficient | 0.18 | 0.13 |
| Total Solar Energy Rejected | 84% | 89% |
| Glare Reduction | 90% | 89% |
| U value, single glazing (W/m².K) | 5.71 | |
| U value, double glazing, Air filled (W/m².K) | 2.72 | |
| Emissivity, εn | 0.76 | |
| Film Colour / Appearance | Neutral Reflective | |
| Installation Position | External | |
Features and Benefits
- Neutral solar control and privacy exterior grade film.
- Provides our highest level daytime privacy with optical transparency.
- Rejects up to 84% of total solar energy, reducing heat and energy costs, increasing comfort.
- One-way daylight privacy with low interior reflection allows improved visibility to the outside while preserving privacy.
- Blocks out 99% of UV radiation, to help prevent fading of furnishings and fittings, as well as the health aspects of too much U.V. light.
- Provides our highest level of daytime privacy with optical transparency.
- SSAF films are protected by a patented scratch-resistant coating, resulting in durable and easy to clean product.
- I.R. 780nm to 2500nm.
Download this Product Page Here
If you would like a sample of this window film please contact us
